The electronic device REW "Prylad AD2.E " is a system of automated influence on the ExpressLRS protocol (ELRS) of known frequency ranges of FPV drones. It can be used both stationary and portable. There is a built-in computer in the electronic device "Prylad AD2.E" that can remotely control the settings of the electronic device "Prylad AD2.E" via static IP addresses of the Internet.
Products
Means of radio electronic warfare "Prylad AD2.E"
Characteristics
|
Name |
Indicator |
|
ExpressLRS (ELRS) Control Protocol Range |
up to 5000 m |
|
The range of scanning operating frequencies |
700-1020 and 2300-2500 MHz |
|
The range of operating frequencies of influence |
700-1020 and 2300-2500 MHz |
|
Working temperature |
-20 … +50 °C |
|
Protection class |
IP-65 |
|
Product body material |
Non-magnetizable metal |
|
Input power supply voltage |
5 V DC |
|
Power consumption |
up to 10 W |
|
Battery life |
at least 12 hours |
|
Output radiation power of products |
3.5 W + 1 W |
|
Product dimensions (LxWxH) |
300x330x220 mm + 30 mm |
|
Product weight |
3.5 kg + 0.5 kg |
|
Uptime/deployment time |
Up to 1 minute |
|
Ethernet output |
It is provided exclusively in the electronic device "Prylad AD2.E" 45160590-002 |
